           3.5 " LCD Screen 640x480 VGA kit for Hand held Oscilloscopes Display, Digital Multi-meter,
Testing Instrument Display, Palm PC Display, Mini Projectors, &  Pocket Electronic Device Display.





















World's smallest  3.5 " LCD 640X480 VGA, workable on virtual SXGA resolution display,

226 dpi ( dot / per inch )  No Substitute ! Built in high color temperature LED back light.



  This 3.5" LCD Is Up Scalable to Virtual 1280 x1024 SXGA. The Following Is A Real Screen Image !   VGA + S-Video Dual Input For Versatile Applications

         The 3.5" LCD Screen  Specs

Model name VT035-VX2
Resolution 640 X 480 VGA
Up Scalable to 1280 x 1024 SXGA
Screen size 3.5" inch
Active area 72 x 52.56 mm,     2.83"x 2.07"
Input connectors VGA port  + S-Video + Composite  NTSC Video
Overall dimensions (W x H x D ) 84.3 W x 65 H x 9.5 D mm,
3.31" W x 2.56" H x 0.37" D  inch
Brightness 250  CD / m2
Back light  type 6 LED ,   30000 hours life
Contrast Ratio 400 : 1
Vewing Angle 100 H,   50 V   degree
Response  time ( ms ) Typ 15,   Max 30  ms
Power connection 12V DC  Jack,  Center pin is  " + "
Power consumption 5 W  ,  < = 500 mA Current drag
Weight 4  Oz
Operating temperature -20~ + 70 C
Shock Test 100 G, 6 ms on X, Y, Z  each directions
Vibration Test 10 ~ 55 Hz , Amplitude 1.0 mm  on X, Y, Z  each directions

Price  $ 250  USD    Minimum Order  2 pcs

See our  VIP Customers   Who use this  VGA 3.5" LCD

3.5" LCD Screen Mechanical  Drawings & Further Specs

Applications

Ideal for hand held digital oscilloscope, digital testing multi-meter, PC104 display, auto-pilot on board display,

cellular phone display, palm PC display, & hand hold electronic displays.

3.5" LCD Screen 640x480 VGA on handheld digital oscilloscope, testing Multi-meter



Innovative Micro  Projection Applications

Head Up Display HUD On Glass Screen Projection

3.5" LCD Screen, 4.8" LCD 1024x600,  5" LCD Screen, 5.6" LCD, 5.7" LCD VGA,  6.3" LCD Screen XGA, 6.4" LCD, 6.5" LCD Screen VGA , 7" LCD Screen 1024x600, 8.4" LCD Screen XGA, 10.4" LCD Screen XGA , 12" LCD Screen, 12.1" LCD 1400x1050, 15" LCD Screen Panel UXGA 1600x1200, 15.4" LCD Panel 1920x1200, 15.6" LCD Screen Panel 1920x1080, 27" LCD Panel 2560x1440, 30" LCD Panel 2560x1600 WQXGA.

Avionics display, Jet Fighter Cockpit Display, Cockpit Simulation LCD Display, EFIS Flight Deck Display, Flight Simulation, Simulator Display, Flight Director LCD Display, Radar Monitor Display, Aircraft Integrated Cockpit Display, Horizontal Situation Indicator display, Flight Director, Flight Advisor LCD display, Integrated Cockpit Display System, HUD Heads Up Display, HMD Helmet Mount Display, UAV Miniature Auto Pilot Micro Module Display, Robotic Control on Body Ultra Compact Display,  PC104 System Display , Micro LCD Projector, Intelligent Mobile Device Display,  Mobile Command Center LCD Display, Night Vision Imaging Display, Submarine Console LCD Display, Mini Handhold PC LCD display, Palm Pilot PC Display, Portable Notebook PC Display,  Industrial Portable Testing Instrument LCD display, etc.
